Coordinates
Description
A (Base Diameter): 2-9/16" (65mm)
B (Projection From Door): 2-5/16" (59mm)
C (Knob Diameter): 2-1/8" (54mm)
B60 Deadbolt
Exterior:
A (Base Diameter): 2-1/2"
B (Projection From Door): 7/8"
Interior:
A (Base Diameter): 2-1/2"
B (Projection From Door): 1-1/4"
C (Thumbturn Length): 1-7/8"
D (Thumbturn Base Plate Thickness): 5/16"
DOOR PREP: Cross Bore: 2-1/8"
Edge Bore: 1"
Latch Face: 1" x 2-1/4"
BACKSET: Adjustable to 2-3/8" or 2-3/4"
DOOR THICKNESS: Standard 1-3/8" to 1-3/4"
KEYED CYLINDER: Pin & Tumbler / 5-Pin Solid Brass Key System / C Keyway
LATCH FACEPLATE: 1" x 2-1/4" Latch options include: round corner or drive-in.
STRIKE PLATES: Knob: 2-1/4" full lip Round Corner Strike.
STRIKE PLATES: Deadbolt: 1-1/8" x 2-3/4"
LATCH BOLT: Knob: Deadlatch - 1/2" Throw.
LATCH BOLT: Deadbolt: Solid Zinc Bolt; Full 1" Throw; 7/8" Housing.
DOOR HANDING: Will work on either right or left hand doors.
ANSI/BHMA: Knob: Grade 2 A156.2
ANSI/BHMA: Deadbolt: Grade 1 A156.5-2001
ADA: N/A
Shipping
DoorLocksDirect.com is located in Tomball, TX. Most orders ship complete within 24 hours. You will get an e-mail once your order has shipped with the UPS tracking #. UPS does not count the day the order is picked up. The number of days in transit start the following day. Weekends or holidays are not counted as transit days.
Calculate Shipping Charges:
- Load items in shopping cart.
- Click checkout button.
- Enter shipping address information.
- UPS shipping options will show cost.
- You can click "Cancel" at any time and keep shopping.
If your order is over $299 (before taxes and shipping charges), the shipping will automatically be removed during checkout (No Coupon Code is required) for Ground shipping charges in the 48 continental states (not valid in Alaska or Hawaii).
Reviews
5 Reviews
-
Schlage Plymouth Antique Brass
Schlage is the very best there is and they offer a wide variety of handset styles and finishes. The Schlage Plymouth style in antique brass does not disappoint, it is noticeably smoother and more substantial then the big box store door lock it replaced. Plus Door Locks Direct was able to key it the same as my existing Schlage door lock, adding to the convenience and letting me avoid having to add still one more key to my key chain.
-
Great Service and Good Locks
I ordered five lock sets to replace old ones in my home. I wanted the deadbolts keyed differently from the handle-sets, but all the deadbolts keyed alike and all the handle-sets keyed alike. A quick call and the representative helped me with exactly how to make the order. The locks are nice and were a (mostly) easy switch. Any issues I had were not with the new locks, but more the way my original locks were installed. One caution is that the screws on the deadbolt have very large heads, so be very careful when tightening as you can scratch the lever. I recommend these locks and DoorLocksDirect.
-
Keyed alike locksets
Great quality, easy installation.
Exactly as expected, quick shipping and well packed. Very pleased. -
ardware Description Plymouth Keyed Knob F51A with B60 Deadbolt Combo Pack The timeless design of the Plymouth works with any style in any room of your home. The Schlage B60 Single Cylinder Deadbolt is a premium security - Grade 1 deadbolt. Feature
OMG these are really good looking doorknobs and deadbolts - and they function so smoothly! LOVE LOVE LOVE them!
-
Replacement Knobs and Deadbolts
I replaced the 30+ year old locking knobs and deadbolts on my house with these. Note that the deadbolt has a removable shroud for fitting into a 2-3/8 in hole. The holes in my door were smaller, so I removed the shroud (one screw) and they fit perfectly. All the locks on my house now have the same key, and doing business with doorlocksdirect.com was great. Highly recommend!
