Schlage
Schlage / Camelot Touchscreen Handleset
- SKU:
- fe469nxcam622
FE 479 Camelot Touchscreen Handleset One of the strongest, most intelligent Bluetooth® - enabled locks available, the Schlage Sense Smart deadbolt gives you the option to enter your home with an access code on its i…
See more
Limited-Time Offers:
Log in to see Price or
Call Toll Free
1-866-755-5625
Due to Allegion PLC's new Minimum Advertised Price (MAP) policy, customers can only see the pricing or purchase Schlage Residential Items when they log-in to an existing member account.
If you do not have a member account, you can create one here: Create Account
Product Details
DOOR PREP: Deadbolt: Cross Bore: 2-1/8" or 1-1/2" Diameter
Edge Bore: 1"
Latch Face: 1" x 2-1/4"
Handle: Cross Bore: 2-1/8"
Edge Bore: 1"
Latch Face: 1" x 2-1/4"
CROSS BORE
SPACING: Standard: 5-1/2" Center to Center (Minimum 4")
BACKSET: Deadbolt: Adjustable to 2-3/8" or 2-3/4"
Handle: Adjustable to 2-3/8" or 2-3/4"
DOOR THICKNESS: Standard: 1-3/8" to 1-3/4" (Doors 1-7/8" - 2-1/2" Order Part #23997877 for deadbolt)
KEYED CYLINDER: Traditional Pin and Tumbler / 5-pin solid brass
LATCH FACEPLATE: Includes 1" x 2-1/4" Round Corner and Square Corner and Drive-In Collar.
STRIKE PLATES: Deadbolt: 1-1/8" x 2-3/4" Round Corner with Strike Reinforcer
Handle: 2-1/4" full lip. Strikes included: Round and Square Corner.
LATCH BOLT: Deadbolt: 1/2" Throw
Handle: Springlatch - 1/2" Throw
DOOR HANDING: Reversible for right or left hand doors. Specify handing when ordering handed
levers as interior trim for handleset
COMMUNICATIONS: Bluetooth Smart
REMOTE ACCESS: Works with Schlage Home App.
ANSI/BHMA: ANSI Grade AAA Highest Residential Security, ANSI/BHMA Commercial Grade 1.
ADA: N/A
FE 479 Camelot Touchscreen Handleset
One of the strongest, most intelligent Bluetooth® - enabled locks available, the Schlage Sense Smart deadbolt gives you the option to enter your home with an access code on its illuminated touchscreen or by using your iPhone®.
Bluetooth® wireless door lock technology that knows the difference between you and your neighbor—ensuring only the right people get in. It's our most advanced lock yet.
The Schlage SenseTM Smart deadbolt is compatible with Apple HomeKitTM technology - which allows you to talk to unlock your door using Siri® on your iPhone®, iPad® or iPod touch®. That connectivity puts you in total control of your home using a device that’s probably already in your pocket. Schlage—a leader in security for over 90 years.
CATEGORY: Keyless Entry Locks
SUB CATEGORY: Camelot Touchscreen Handleset
COLLECTION: Schlage FE Series / Electronic Touchscreen Handleset
PRODUCT FAMILY: Camelot
STYLE: Single Cylinder Touchscreen Handleset
INTERIOR: Deadbolt Thumbturn & Accent Lever on interior.
EXTERIOR: ANSI Grade AAA Highest Residential Security, ANSI/BHMA Commercial Grade 1.
5-Pin Solid Brass Key System.
1/2" Deadbolt Throwbolt | 1/2" Springlatch on Handleset
KEY QUANTITY: 1 Key
FINISH: Satin Nickel - 619
FUNCTION: Single Cylinder Handleset / Typically used on front entry doors.
The deadbolt is operated by a code or key on the exterior and a thumbturn on the interior.
WARRANTY: Manufacturer 3 year electronics / limited lifetime mechanical and finish.
SHIPPING WEIGHT: 10.0 lbs.
Helpful Hint:
Please contact us with any questions @ 1-866-755-LOCK (5625).
One of the strongest, most intelligent Bluetooth® - enabled locks available, the Schlage Sense Smart deadbolt gives you the option to enter your home with an access code on its illuminated touchscreen or by using your iPhone®.
Bluetooth® wireless door lock technology that knows the difference between you and your neighbor—ensuring only the right people get in. It's our most advanced lock yet.
The Schlage SenseTM Smart deadbolt is compatible with Apple HomeKitTM technology - which allows you to talk to unlock your door using Siri® on your iPhone®, iPad® or iPod touch®. That connectivity puts you in total control of your home using a device that’s probably already in your pocket. Schlage—a leader in security for over 90 years.
- Durable, Smart Design, Slim Profile, sleek without sacrificing strength.
- Programming and using the lock is as simple as using an app.
- No incremental fees, no subscriptions and no additional payments for electronic access.
- Built-in alarm sensors; senses potential attacks and can issue an alert
- Fingerprint resistant, works in the rain and when wearing gloves.
- Low Battery Warning (4 - AA Batteries).
- Illuminated touchscreen.
- iOS and Android smartphones.
- Lock /unlock remotely with Schlage Sense WiFi adapter (sold separately) when adapter is connected to WiFi or within Bluetooth range (about 40' feet from lock).
- Use Schlage Home App to manage access codes and share virtual keys.
CATEGORY: Keyless Entry Locks
SUB CATEGORY: Camelot Touchscreen Handleset
COLLECTION: Schlage FE Series / Electronic Touchscreen Handleset
PRODUCT FAMILY: Camelot
STYLE: Single Cylinder Touchscreen Handleset
INTERIOR: Deadbolt Thumbturn & Accent Lever on interior.
EXTERIOR: ANSI Grade AAA Highest Residential Security, ANSI/BHMA Commercial Grade 1.
5-Pin Solid Brass Key System.
1/2" Deadbolt Throwbolt | 1/2" Springlatch on Handleset
KEY QUANTITY: 1 Key
FINISH: Satin Nickel - 619
FUNCTION: Single Cylinder Handleset / Typically used on front entry doors.
The deadbolt is operated by a code or key on the exterior and a thumbturn on the interior.
WARRANTY: Manufacturer 3 year electronics / limited lifetime mechanical and finish.
SHIPPING WEIGHT: 10.0 lbs.
Helpful Hint:
- This unit requires the same door preparation as a standard keylock and deadbolt.
- There is no hard wiring necessary as this unit operates on 4 - AA Batteries. Batteries are included with product.
Please contact us with any questions @ 1-866-755-LOCK (5625).
FE479NX Camelot Touchscreen Handleset
Exterior:
A - (Deadbolt Height): 5 Inches
B - (Deadbolt Width): 3 Inches
C - (Deadbolt Projection From Door): 1 Inch
D - (Handle Height): 12.87 Inches
E - (Handle Projection From Door): 2.87 Inches
Interior:
F - (Deadbolt Height): 8 Inches
G - (Deadbolt Width): 3 Inches
H - (Deadbolt Projection From Door): 2 Inches
I - (Base Diameter): 2.75 Inches
J - (Lever Projection From Door): 2.71 Inches
K - (Bolt Cover Cap Diameter): 1.24 Inches
Exterior:
A - (Deadbolt Height): 5 Inches
B - (Deadbolt Width): 3 Inches
C - (Deadbolt Projection From Door): 1 Inch
D - (Handle Height): 12.87 Inches
E - (Handle Projection From Door): 2.87 Inches
Interior:
F - (Deadbolt Height): 8 Inches
G - (Deadbolt Width): 3 Inches
H - (Deadbolt Projection From Door): 2 Inches
I - (Base Diameter): 2.75 Inches
J - (Lever Projection From Door): 2.71 Inches
K - (Bolt Cover Cap Diameter): 1.24 Inches
DOOR PREP: Deadbolt: Cross Bore: 2-1/8" or 1-1/2" Diameter
Edge Bore: 1"
Latch Face: 1" x 2-1/4"
Handle: Cross Bore: 2-1/8"
Edge Bore: 1"
Latch Face: 1" x 2-1/4"
CROSS BORE
SPACING: Standard: 5-1/2" Center to Center (Minimum 4")
BACKSET: Deadbolt: Adjustable to 2-3/8" or 2-3/4"
Handle: Adjustable to 2-3/8" or 2-3/4"
DOOR THICKNESS: Standard: 1-3/8" to 1-3/4" (Doors 1-7/8" - 2-1/2" Order Part #23997877 for deadbolt)
KEYED CYLINDER: Traditional Pin and Tumbler / 5-pin solid brass
LATCH FACEPLATE: Includes 1" x 2-1/4" Round Corner and Square Corner and Drive-In Collar.
STRIKE PLATES: Deadbolt: 1-1/8" x 2-3/4" Round Corner with Strike Reinforcer
Handle: 2-1/4" full lip. Strikes included: Round and Square Corner.
LATCH BOLT: Deadbolt: 1/2" Throw
Handle: Springlatch - 1/2" Throw
DOOR HANDING: Reversible for right or left hand doors. Specify handing when ordering handed
levers as interior trim for handleset
COMMUNICATIONS: Bluetooth Smart
REMOTE ACCESS: Works with Schlage Home App.
ANSI/BHMA: ANSI Grade AAA Highest Residential Security, ANSI/BHMA Commercial Grade 1.
ADA: N/A
Warranty Information
Kwikset Warranty
Mechanical & Finish Coverage: Both are covered for as long as the original purchaser occupies the home where the product was installed.
Electronics Coverage: Electronic components are covered for 1 year from purchase.
Authorized Seller Requirement: Warranty applies only to products purchased from Kwikset-authorized sellers (like Door Locks Direct); unauthorized purchases are not eligible.
Exclusions: No coverage for misuse, improper installation, chemical damage, commercial use, modifications, or mixing Kwikset with non-Kwikset trim; warranty is non-transferable.
Claims Process: Proof of purchase and defect description required; Kwikset may provide troubleshooting or replace the product and supplies a prepaid return label if a return is authorized.
For more details please visit Kwikset.com
Schlage Warranty
Mechanical & Finish Coverage: Most Schlage residential products include a Limited Lifetime Mechanical and Finish Warranty.
Electronics Coverage: Smart and electronic products carry a 3-year electronics warranty.
Original User & Authorized Seller Requirement: Warranty applies only to the original residential user, is non-transferable, and requires purchase from a Schlage-authorized seller (like Door Locks Direct).
Exclusions: No coverage for labor, normal wear, improper installation, misuse, environmental damage, commercial/common-area use, or Oil-Rubbed Bronze finish changes.
Schlage Remedy: Upon inspection, Schlage may replace with new/remanufactured product or refund the purchase price; customer must return the product with proof of purchase.
For more details please visit Schlage.com
Reviews
1 Review
-
Great Product!
Wife wanted all exterior door brass hardware replaced with satin nickel. This is what I selected for the front door and it looks great. Easy to install and the schlage sense dead bolt is awesome. I really like the auto lock feature and the app makes the setup a breeze. This is a second home so the remote unlocking capability with my phone is really nice. Also by using doorlocks direct this was keyed the same as all the other hardware I purchased which was awesome!
