Kwikset / Trafford Lever

The Trafford Passage Lever is a straight, decorative lever with modern industrial touches. Part of the Kwikset Signature Series, these non-locking levers are perfect for indoor use such as halls and closets. With a reversible lever chassis, these interior door lever handles work for either left or right-handed operation.

CATEGORY:                    Door Levers

MANUFACTURER:         Kwikset Corporation

COLLECTION:                Kwikset Signature Series

PRODUCT FAMILY:        Trafford

STYLE:                            Decorative lever.

INTERIOR:                      Decorative Rose / Easy Installation

FINISH:                            Venetian Bronze - 11P

FUNCTION:                     Passage / Typically used on hall or closet doors.
                                         Both levers always free (non-locking).

HANDING:                       This lever will work on either a right or left hand door application.
                                         Reversible lever chassis (non-handed product).

WARRANTY:                   Manufacturer - Lifetime Mechanical / Lifetime Finish

SHIPPING WEIGHT:       2.42 lbs.

Please contact us with any questions @ 1-866-755-LOCK (5625).

A (Base Diameter):              2-21/32"
B (Lever Length):                 4-5/32"
C (Projection From Door):    2-19/32"

DOOR PREP:                  Cross Bore: 2-1/8"
                                         Edge Bore: 1"
                                         Latch Face: 1" x 2-1/4"

BACKSET:                       Adjustable to 2-3/8" or 2-3/4"

DOOR THICKNESS:       Standard 1-3/8" to 1-3/4"
                                         Optional 2-1/4" thick door pack (See Parts & Accessories) #81706 Knobs & Levers Thick Door Pack

CYLINDER:                      N/A

LATCH INCLUDED:         6-Way Latch: round corner, square corner and drive-in collar (Face Plate 2-1/4" Tall x 1" Wide).



STRIKE PLATE:               2-1/4" full lip strike (2-14" Tall x 1-3/4" Wide).


                                          Need a different strike plate?:  Optional Strikes Plates for Purchase

LATCH BOLT:                   Plainlatch - 1/2" throw. Nickel plated.

DOOR HANDING:            Will work on either right or left hand doors.

ANSI/BHMA:                    A156.2 Grade 2.

ADA:                                This function satisfies section 4.13.9 ADA requirement.
