Kwikset

Kwikset / San Clemente Handleset / Single Cylinder - SmartKey

2 reviews Write a Review
SKU:
818sce514smt
UPC:
883351646031

San Clemente Single Cylinder Handleset The modern lines of the San Clemente handleset makes a strong statement to your décor with its square cornering and distinct details. CATEGORY:     â€¦

See more
Limited-Time Offers:
$372.10
$156.90
(You save: $215.20 )
Selected Finish is

Finish will match your handleset selection

Hurry up! only left
Adding to cart… The item has been added
Product Details
San Clemente Single Cylinder Handleset

The modern lines of the San Clemente handleset makes a strong statement to your décor with its square cornering and distinct details.

CATEGORY:                   Handlesets

MANUFACTURER:         Kwikset Corporation

COLLECTION:                Kwikset Signature Series

PRODUCT FAMILY:        San Clemente

STYLE:                            Two-Piece Decorative Handleset

INTERIOR:                       Select Interior Knob or Lever

EXTERIOR:                      Heavy Duty Residential Grade 1 Security Deadbolt / 1" Steel Deadbolt Latch
                                          Solid Forged Brass

KEYED CYLINDER:         SmartKey Cylinder with BumpGuard Feature
                                                             Kwikset SmartKey Cylinder        Kwikset BumpGuard Standard on SmartKey Cylinders

FINISH:                             Satin Nickel - 15

FUNCTION:                      Single Cylinder Handleset / Typically used on front doors.
                                          The handle latch bolt is operated by a thumbpiece on the exterior and a knob or lever on the interior.
                                          The deadbolt is operated by a key on the exterior and a thumb turn on the interior.

WARRANTY:                    Manufacturer - Lifetime Mechanical / Lifetime Finish

SHIPPING WEIGHT:        7.90 lbs.

Please contact us with any questions @ 1-866-755-LOCK (5625).

San Clemente Handleset Dimensions

Thru Bolt Dimensions

A (Exterior Projection From Door):                                                       2-5/8"
B (Cross Bore Hole Spacing - Center to Center):                                5-1/2"
C (Center of Cross Bore Handle Hole to Bottom Tie Bolt/Screw):       8-13/32" Through 9-11/16"
D (Overall Handleset Height):                                                              17-29/32"

DOOR PREP:                Deadbolt:  Cross Bore:  2-1/8" or 1-1/2"
                                                         Edge Bore:  1"
                                                         Latch Face:  1" x 2-1/4"
                                       Handle:     Cross Bore:  2-1/8"
                                                         Edge Bore:  1"
                                                         Latch Face:  1" x 2-1/4"

BACKSET:                    Deadbolt:   Adjustable to 2-3/8" or 2-3/4"
                                       Handle:      Adjustable to 2-3/8" or 2-3/4"

DOOR THICKNESS:     Standard 1-3/4"
                                       Optional 2-1/4" thick door pack (See Lock Parts & Accessories) Handleset Thick Door Packs

KEYED CYLINDER:      SmartKey Cylinder with BumpGuard Feature
                                                             Kwikset SmartKey Cylinder        Kwikset BumpGuard Standard on SmartKey Cylinders

LATCH FACEPLATE:   1" x 2-1/4" Latch faceplate includes:  Round Corner, Square Corner or Drive-In for Deadbolt and Handle.
STRIKE PLATES:          Deadbolt:  1-1/8" Wide x 2-3/4" Tall strike plate (Round and Square corner).
                                       Handle: 1-3/4" Wide x 2-1/4" Tall full lip round corner strike.


                                       Need a different deadbolt strike plate?:  Optional Strikes Plates for Purchase

LATCH BOLT:                Deadbolt:  Brass Bolt; Full 1" Throw; Titanium Alloy Roller Pin
                                       Handle:     Plainlatch -  1/2" throw; nickel plated.

DOOR HANDING:         Reversible for right or left hand doors.  Specify handing when ordering handed
                                       levers as interior trim for handleset (Interior Knob or Lever Options).

ANSI/BHMA:                 A156.5 Grade 1 for deadbolt.

ADA:                              N/A

Warranty Information

Kwikset Warranty

Mechanical & Finish Coverage: Both are covered for as long as the original purchaser occupies the home where the product was installed.

Electronics Coverage: Electronic components are covered for 1 year from purchase.

Authorized Seller Requirement: Warranty applies only to products purchased from Kwikset-authorized sellers (like Door Locks Direct); unauthorized purchases are not eligible.

Exclusions: No coverage for misuse, improper installation, chemical damage, commercial use, modifications, or mixing Kwikset with non-Kwikset trim; warranty is non-transferable.

Claims Process: Proof of purchase and defect description required; Kwikset may provide troubleshooting or replace the product and supplies a prepaid return label if a return is authorized.

For more details please visit Kwikset.com

Schlage Warranty

Mechanical & Finish Coverage: Most Schlage residential products include a Limited Lifetime Mechanical and Finish Warranty.

Electronics Coverage: Smart and electronic products carry a 3-year electronics warranty.

Original User & Authorized Seller Requirement: Warranty applies only to the original residential user, is non-transferable, and requires purchase from a Schlage-authorized seller (like Door Locks Direct).

Exclusions: No coverage for labor, normal wear, improper installation, misuse, environmental damage, commercial/common-area use, or Oil-Rubbed Bronze finish changes.

Schlage Remedy: Upon inspection, Schlage may replace with new/remanufactured product or refund the purchase price; customer must return the product with proof of purchase.

For more details please visit Schlage.com

Reviews

2 Reviews

  • Front door lock
    5

    Posted by Dave on Nov 27, 2021

    Very sharp looking front door Handel and lock.

  • Kwikset San Clemente handleset
    4

    Posted by Thomas Kryka on Sep 9, 2021

    My wife loves the style. The only problem I had was with the latches. I was replacing an existing lock and could not use the size as shipped. I ordered 2 3/4" and the instructions on how to adjust the latch backset to that size were easy to overlook. A separate sheet with that detail added in with the latches would have made my work a lot easier.
