Schlage / Plymouth Handleset / Dummy Cylinder / Matte Black / F93PLY 622

Write a Review
Item: f93ply622

Matching Hardware

    31276,29671,33175,33333,34810,30546,30141,29575

Coordinates

Description

Plymouth Dummy Handleset

The timeless design of the Plymouth works with any style in any room of your home.

CATEGORY:                    Handlesets

MANUFACTURER:         Schlage

COLLECTION:                F Series

PRODUCT FAMILY:       Plymouth

STYLE:                            Two-Piece Decorative Handleset

INTERIOR:                       Select Interior Knob or Lever

EXTERIOR:                     Solid Forged Brass / Concealed Screws

FINISH:                            Matte Black - 622

FUNCTION:                     Dummy Cylinder Handleset
                                         Typically used on inactive leaf of double front doors.
                                         Handle and grip act as a pull only - no operation.
                                         This handleset is designed for decorative purposes only.

WARRANTY:                  Lifetime Limited Finish and Mechanical

SHIPPING WEIGHT:      5.65 lbs.

Helpful Hint:    Even though this handleset is a dummy function, it still requires two 2-1/8" cross bore holes for mounting.

Please contact us with any questions @ 1-866-755-LOCK (5625).
Plymouth Handleset

Plymouth Handleset Dimensions    Plymouth Throughbolt Dimensions

A (Handle Length):                                                                               12-13/32"  (315mm)
B (Cross Bore Hole Spacing - Center to Center):                                 5-1/2"    (140mm)
C (Projection From Door):                                                                     2-9/32"    (64mm)
D (Center of Cross Bore Handle Hole to Bottom Tie Bolt/Screw):        Adjustable 8-1/4" to 9-7/8"
Plymouth Dummy Handleset

DOOR PREP:                  Deadbolt:  Cross Bore:  2-1/8" or 1-1/2"
                                                         Edge Bore:  N/A
                                                         Latch Face:  N/A
                                       Handle:     Cross Bore:  2-1/8"
                                                         Edge Bore:  N/A
                                                         Latch Face:  N/A

BACKSET:                      Deadbolt:  N/A
                                       Handle:      N/A

DOOR THICKNESS:        Standard:   1-5/8" to 2".
                                       Packed with extra mounting screws to accommodate 2" doors.

CYLINDER:                     N/A

LATCH FACEPLATE:     N/A

STRIKE PLATES:            Deadbolt:  N/A
                                       Handle:      N/A

LATCH BOLT:                Deadbolt:  N/A
                                        Handle:     N/A

DOOR HANDING:            Reversible for right or left hand doors.  Specify handing when ordering handed
                                        levers as interior trim for handleset (Interior Knob or Lever Options).

ANSI/BHMA:                   N/A

ADA:                               N/A

Please contact us with any questions @ 1-866-755-LOCK (5625).
